Stomp E-box 1

Stomp E-Box 1

Wired electric pit bikes Wired electric pit bikes Wired electric pit bikes Wired electric pit bikes
Frame typeDouble Cradle
Front wheel size12"
Rear wheel size10"
Front brakeHydraulic Disc
Front disc180mm
Rear brakeHydraulic Disc
Rear disc180mm
Front tyre12" x 2.27"
Rear tyre10" x 3"
Chain219H
GearingFront 10T, Rear 70T
Max load85kg
Shock typeMono shock
Fork typeUSD
HandlebarAloy
Motor voltage48v
Peak power1.6KW (2.1hp)
Max rpm4100
Battery48V 15.6Ah Lithium
Controller output42A
ChargerAC 110-240V, output: 54.6V, 2A
Charge time7-8 hours
Range per change28-30 Km
Top speed48 Km/h
External adjustabilityTop speed, Acceleration
Frame constructionHigh strength steel, powder coated, removable subframe, swing arm mounted motor, non linkage suspension
Wheelbase920mm
Ground clearance235mm
Seat height63cm

Stomp is proud to announce the introduction of the first of its EBOX range, the 48v 1.6kw EBOX 1.

Designed by our engineers and product designers from the ground up to be lightweight, powerful and outperform any other sub £3000, 12/10” bike on the market.

EBOX 1 is a 1.6 KW lithium battery / brushless motor combination that packs an astonishing punch. So-much-so, during development we had to add speed-controller adjustment because it was literally too savage. The benefit is that EBOX1 can be controlled to perfection, dialled down for entry level riding and turned up when you are ready to pin it to clear that table.

EBOX 1 will easily pull wheelies off the throttle with a 90 kg adult rider and top-out (quickly) at around 28 mph (more than enough for track use).

Aimed at entry level riders from 6 years up, the EBOX 1 is fully compliant with CE and UKCA testing standards. This is a proper bike for serious riders. The perfect, near-silent stepping-stone for every kid with motocross dreams!

A solid hours riding is easily achieved at full power settings and that can be extended by changing the battery should you need more track time.

Key features: charge level indicators, lightweight disk brakes, upside down forks, mono shock, 16.6 AH lithium battery and power delivery control.
